Curtain Wall System SMARTIA M50

Curtain Wall System SMARTIA M50

Description

SMARTIA M50 is a complete system for curtain walls with high energy efficiency, which offers infinite design
possibilities and meets every requirement
of contemporary architecture.

Advantages

  • Minimal Design
  • High Energy Efficiency
  • Increased Comfort level
  • Increased of security level
  • Increased of sound insulation level
  • Maximum functionality
  • Enhancement of Natural Light
  • Guaranteed performance quality in terms of air- water permeability, wind pressure as well as the Uf.
  • Increased static and functionality in extreme natural phenomena
  • Flexibility in construction
  • Vast alternatives in custom solutions tailor made to the building
  • Ease of use with electric motion

Certificates

  • Cradle to Cradle Certified® is the global standard for products that are safe, circular and responsibly made.
  • Aluminum TUV Austria OK Recycled

Generic

AESTHETICS
Standard

Technical Characteristics

EXTERIOR VISIBLE WIDTH
50 mm

Performance

IMPACT RESISTANCE
I5 /E5
SECURITY OF VISIBLE LOAD
Design Load ±3 KN/m2
WATER TIGHTNESS
R7
AIR PERMEABILITY
AE
WIND LOAD RESISTANCE
Design Load ± 2 KN/m1
SOUND REDUCTION
32, 42,47
BURGLAR RESISTANCE
RC3
FIRE RESISTANCE
E30, EW30
BULLET RESISTANCE
FB6S, FB4

Characteristics

TRANSOMS MAX INERTIA
1300
MULLION DEPTH
12 up to 234 mm
TYPES OF TYPOLOGY
Fixed, Projected, Parallel Projected
MULLION MAX INERTIA
1300
MAXIMUM WEIGHT
180 Kg
UF
from 1,0 up to 1,8 W/m²K
TRANSOM DEPTH
12 up to 234 mm
TYPE OF INSTALLATION
Standard
TYPE OF HOLDING GLAZING
Pressure Plate or Structural Silicon
TYPOLOGIES

All available typologies

01
Tilt and turn window
02
Parallel and projected outward window
03
Hinged opening outward door
04
Hinged opening inward door
05
Projected outward window
06
Parallel projected outward window
