Minimal Sliding insulated system SMARTIA M630 PHOS

Minimal Sliding insulated system SMARTIA M630 PHOS

Description

The sliding system SMARTIA M630 PHOS offers a minimal touch in contemporary residences combining minimal design with high thermal performance. Following the “less is more” philosophy, all aluminium profiles can be hidden into the wall providing a total sense of comfort with top functionality and enhanced safety.

Αsk for information

Get a quote

Advantages

Elegant coziness full of natural light thanks to the system's minimal design and the wide glazing surfaces
High energy saving thanks to the exceptional thermal performance
Exceptional sound insulation
Maximum ease of use and high functionality
Ease of access ideal for children, the elders and people with special needs
Wide variety of typologies
Exceptional quality with certified performance

Certificates

Generic

WINDOW TYPE

Sliding

THERMAL INSULATION

Yes

EXTERIOR SHAPE

Flat

SURFACE TREATMENTS

Wood sublimation , Anodizing colors, all powder coating

Technical Characteristics

SASH DEPTH

63 mm

MINIMUM VISIBLE ALUMINIUM FACE HEIGHT

Concealed profiles

MINIMUM VISIBLE ALUMINIUM FACE WIDTH AT THE CENTRAL VERTICAL COLUMN (INTERLOCKING PROFILE)

44 mm

GLAZING TYPE

Double - Triple

MAXIMUM GLAZING THICKNESS

up to 32 mm

SEALING METHOD

Perimetrical with tri-fin brushes

MINIMUM THRESHOLD HEIGHT

32 mm

TYPE OF THERMAL INSULATION

Polyamides, Thermoplastic

Performance

UW

1,43 W/m2K

WATER TIGHTNESS

CLASS 7A

AIR PERMEABILITY

CLASS 4

WIND LOAD RESISTANCE

C5

SOUND REDUCTION

42dB

Characteristics

SASH WEIGHT

up to 250 Kg

TYPES OF TYPOLOGY

Horizontal sliding sashes, Meeting stile, Combinations with fixed ligths

TYPOLOGIES

All available typologies

Double horizontal sliding sash

Double horizontal parallel sliding window with fly-screen

Single sash sliding window with fix pane

Triple horizontal sliding sash

Four horizontal sliding sashes with meeting stile

quadruple horizontal parallel sliding with meeting stile & fly-screen

Double horizontal sliding sash meeting stile with fixed lights

Single pocket sash

Double pocket sash meeting stile with flyscreen

Single pocket sash with flyscreen

Double pocket sash meeting stile with flyscreen

Corner typology

Media Gallery

Sections
