Entrance doors insulated system SUPREME SD115

Entrance doors insulated system SUPREME SD115

Description
ALUMIL creates new horizons for modern residential and industrial design thanks to the innovative design of the system SUPREME SD115 Pivot that offers extremely large entrance doors for an exceptional aesthetic result with a pure, minimalistic design and coplanar surfaces.

The system SUPREME SD115 Pivot provides an outstanding new feeling of brightness and connection between internal and external environments, rendering the system unique in concept and design.

The innovative design of the system, alongside the state-of-the-art equipment, provide the prerequisites for prestigious entrance doors with high aesthetics, exceptional quality and outstanding performances in terms of security, insulation, and functionality.
Add to favorites
Advantages
  • High security level
  • Modern design
  • Maximum energy saving thanks to the exceptional thermal
  • Ease of access ideal for people with disabilities and children
  • Exceptional sound insulation
  • Ease of use and high functionality
Generic
THERMAL INSULATION
Yes
EXTERIOR SHAPES
Flat
SURFACE TREATMENTS
Vopsire in camp electrostatic, all powder coating, Polished anodizing, Anodizing colors, Wood sublimation
Technical Characteristics
FRAME DEPTH
115 mm
MAXIMUM GLAZING THICKNESS
115 mm
MECHANISM
Multiple points lock
SEALING METHOD
Perimetrical at 3 levels with EPDM gaskets
MINIMUM THRESHOLD HEIGHT
7 mm
TYPE OF THERMAL INSULATION
Polyamides 34 mm width, ALUMIL Energy bar, Insulation foam
Performance
BURGLAR RESISTANCE
RC3
TYPES OF TYPOLOGY
Single leaf pivot doors
UF
from 0,75 W/m²K
SASH DEPTH
115 mm
SASH WEIGHT
up to 250 Kg
MINIMUM VISIBLE ALUMINIUM FACE HEIGHT
70 mm
TYPOLOGIES

All available typologies

01
Hinged door with insulation panel
02
Hinged door with insulation panel & fixed pane
03
Hinged door with insulation panel, fixed pane & fanlight
